18-pulse VFD drive

Our 18-pulse VSD provides low harmonic distortion through phased cancellation of primary harmonics (5th and 7th) and the higher order harmonics that could cause resonance on capacitive and inductive loads (such as filters, transformer, etc.).

Because cost can be prohibitive for most building applications, only consider this for facilities that have significant harmonics on the electrical system. The THD at the input terminals can be less than 5%; therefore, lower total voltage harmonic distortion will be realized at the source, depending on the circuit impedance.

Features of our 18-pulse VSD (18-pulse VFD drive):

1. Clean power (low harmonic content) for high-horsepower ratings

2. Compliance to IEEE 519

3. High efficiency (low losses) results in energy savings.

4. Improved total power factor

5. Customized for specific applications

6. Advanced technology platform increases reliability and uptime

7. Improves overall electrical system efficiency

Suitable for the applications:

Municipal – Water and effluent treatment facilities, pump and lift stations;

Oil and gas – Pipeline pumps;

Power utilities – Pumps, fans, and blowers;

Compressors – HVAC chiller plants;

Conveyors – Mining and other large conveying systems;

Others – Irrigation systems, blowers, etc.
